Offshore Automatic Pipe Welding Machine For Pipe Spool Prefabrication

Short Description:


  • Min.Order Quantity: 1 Piece
  • Port: Shanghai
  • Brand Name: YouBest
  • Place of Origin: Jiangsu,China
  • Product Detail

    Send Inquiry

    Offshore Automatic Pipe Welding Machine For Pipe Spool Prefabrication is specially designed for straight pipe/pipe, pipe/fittings (including elbow, tee, and reducer), and pipe/weld-neck flange butt joint connection welding. This system is welding application with auto-switch TIG or MIG/MAG/SAW welding torches which is for automatic TIG welding for root pass and TIG/MIG/MAG/SAW welding fill/cap within the diameter of 2~24″ and length of 6m standard pipe.

     Youbest Offshore Automatic Welding System includes welding machines, line-up clamps, pipe facing machines, and independent power supplies. Among our many automatic welding innovations are tandem-wire and dual-torch technologies for faster welding; through-the-arc tracking for more accurate welds; and digital-to-digital programming, onboard data collection, and touch-screen control to reduce errors and downtime. Designed for unique offshore working conditions, the Offshore Automatic Welding System allows you to maximize productivity from a limited number of welding stations so you can boost operational speed, maintain high quality levels and keep your offshore pipeline project on schedule.

    •  pipe material: CS , SS , Cr
    • Pipe OD:2-24″
    • wall thickness: 3-60mm
    • Length of the pipes before welding: ≤ 6m
    • Used in workshop
    • Welding quality requirement: 100% X rays
    •  Welding capacity per day: 200-250D.I



    Welding process:

    •  TIG root、filling、capping welding;
    •  TIG root、MIG filling、capping welding
    • TIG root、SAW、capping welding
